Complies with IEEE802.3af/at Standard
● Supports PoE power up to 32W for each PoE port
● Auto detect non PoE device and PoE device
● Power prioritization guarantee power supply of key nodes
● CCTV/VLAN mode switch, remote power and data up to 250m
● Supports IEEE802.3 x full duplex / half duplex flow control
● Supports storage and forward for Data exchange
| Model | FS1006P |
| PoE standard | IEEE802.3af/at |
| Interface | 6*10/100Mbps RJ45 port |
| key function | CCTV |
| PoE port | 1-4 |
| PoE Total | 60W |
| Power supply | 65W |
| RJ45 PoE power supply | Mode A Anode1/2 Cathode3/6 |
| PoE output-port | Max 32W |
| Indicator | PWR, LNK/ACT, PoE |
| Network media | 10BASE-T: UTP category 3, 4, 5 cable(≤100m)；100BASE-TX: UTP category 5, 5e cable(≤100m) |
| MAC Address Table | 2K, Automatic study, automatic updates |
| jumbo frame | 1528K Bytes |
| Packet buffer | 768K bit |
| Transfer Mode | Store-and-forward |
| Packet forwarding rate | 0.89Mpps |
| Bandwidth | 1.2Gbps |
| Fan | Fanless |
| Device Dimension | 168*93*32mm |
| Machine weight | <1kg |
| Input Voltage | AC 100-240V 50/60Hz |
| Output Voltage | DC:55V/1.5A |
| Operating Temperature | 0°C ~ 40 °C |
| Storage Temperature | -40 °C ~ 70 °C |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Humidity | 5% ~ 90% non-condensing |
| Surge Protection | ±4KV |
| Certification | CE, FCC Class A |
| MTBF | >50000 hour |
| Electrostatic standard | Contact 4KV, air 6KV |
● 10/100 Mbps Ethernet Ports
● IEEE 802.3af/802.3at compliant
● 60W total PoE Power supply.
● Ideal for installations of 4 PoE/PoE+ devices
● Pin assignment: alternative 1/2 (+), 3/6 (-).
● Provide a variety of installation methods for easy deployment in any environment
● Support Wall mount installation
● Support Desktop installation
● Made of high-quality metal case, sturdy and durable with long service life, provide better heat dissipation, suitable for most environment.
● Venting holes help to dissipate heat quickly and ensure stable product operation
● Texas Instruments TPS POE chipset and Realtek switch chipset ensure High performance and stable operation of the product.
● Port-Power-Prioritization technology ensure continuous power supply of key nodes.
● Auto-sensing technology delivers up to 32W to an 802.3at PoE+ device with backwards compatibility for 802.3af PoE (15.4W) devices
● Electrostatic standard: contact 6KV, air 8KV
● MTBF > 50000 hour
