1*10/100Mbps PoE output port with 802.3af/at 24W
● 1*10/100Mbps Ethernet input port
● AC IN 100-240V
● Plug and play, no configuration
| HARDWARE FEATURES | WI-POE31-48V |
| Interface | 1 10/100Mbps PoERJ45 Port |
| 1 10/100Mbps Ethernet Port | |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) |
| EIA/TIA-568 100Ω STP (Max 100m) | |
| 100BASE-TX: UTP category 5, 5e cable (Max 100m) | |
| EIA/TIA-568 100Ω STP (Max 100m) | |
| Power Supply | AC IN 100-240V |
| Data In/Out | 1 x 10/100Mbps Data In |
| Power In/Out Port | 1 x 802.3af/at PoE Out |
| PoE PIN | 4/5(+) 7/8(-) or 1/2(+) 3/6(-) |
| PoE Consumption | 48V 24W |
| LED Indicator | PWR-Power |
| DIP Switch | N/A |
| Fan Quantity | Fanless |
| Transmission Method | Store-And-Forward |
| Protection Level | 6kV Lightning protection |
| 6kV ESD Contact discharge | |
| Advanced Functions | Mac Address Auto-Learning And Auto-Aging |
| Store and forward | |
| IEEE 802.3x flow control for | |
| Full-duplex Mode | |
| Backpressure for Half-duplex Mode | |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Dimension | 205×134×47mm |
| DeviceDimension | 113×48×30mm |
| Gross Weight | 0.3kg |
| Net Weight | 0.12kg |
| Warranty | 3 Years |
